CE Certified
BIS Certified
Make in India
- Lowest face recognition time <0.5Sec for improve speed of operation to control rush
- Unique Live Face recognition
- Face recognition with Alarm warning
- 10K Face capacity & 80K capture records
- Support real time live detection
- 3D noise reduction and FOG passing technology
- Audio-Voice playback in regional language for event
- 4.3 inch IPS HD Display
- 2 megapixel dual camera
|
Parameter |
Description |
|---|---|
|
Display |
4.3 inches IPS HD screen |
|
Processor |
Dual Core Processor + 1GB memory + 8G flash |
|
Operating System |
Linux Operating System |
|
Sensor |
1/2.8" Progressive Scan CMOS |
|
Viewing angle |
Vertical viewing angle: 30°; Horizontal viewing angle: 30° |
|
Camera |
Dual cameras with 2MP, 1920×1080, 6mm lens |
|
Audio |
Voice playback in regional language |
|
Recognition height |
1.2—2.2 meters |
|
Recognition distance |
0.5—1.5 meters |
|
Recognition time |
Less than 0.5 seconds |
|
Store capacity |
60,000 capture records |
|
Face capacity |
10,000 |
|
Communications Port |
TCP/IP, RS485, Wi-Fi* |
|
Wiegand interface |
Wiegand interface input/output |
|
Input |
3 I/P (Door Status, Egress, Fire) |
|
Output |
Door Lock |
|
Reader |
Mifare Smart Card Reader (13.56Mhz) *Optional |
|
Operation mode |
Face + Card |
|
Tamper Alarm |
Available |
|
Power Supply |
12 V DC/ 2A |
|
Operating Temp & Hum. |
Temp: –30° ~ +60°, & Rh: 0 ~ 90% |
|
Ingress Protection |
IP42 |
|
Size in mm |
88 mm × 160 mm × 17 mm |
|
Mounting |
Wall Mounting |
|
Weight |
1 kg |
